Formwork LVL
Formwork LVL is Laminated Veneer Lumber specifically engineered for concrete formwork applications by formwork trade professionals. Big River stocks the biggest range of Formwork LVL in the country for all your concrete formwork needs. Stronger, lighter, straighter and more uniformity, so you can be sure to get the exact length and depth you need for your specific application, resulting in a better concrete finish.
Showing 4 products
e-form
Wesbeam e-form is engineered LVL formwork beams with wax-coated protection, strength, straightness and durability for demanding concrete construction environments.
Formwork
FormBEAM LVL
Purpose-engineered Laminated Veneer Lumber (LVL) for high-performance concrete formwork applications.
Formwork LVL
Scaffold Plank
Big River Group’s Scaffold Plank is recognised for its safe and dependable performance.
Scaffold planking
TruForm
High-strength LVL beams for formwork and structural applications
Commercial formwork systems
TRADE TIPS
What to look for when choosing your Formwork LVL
What is the main Formwork LVL manufacturing standard?
All genuine structural Formwork LVL in Australia is manufactured to AS/NZS 4357 (Structural Laminated Veneer Lumber), with quality control independently third-party audited and certified — Big River’s e-form and TruFORM are both EWPAA-certified to that standard. Before anything else, confirm the LVL you’re buying is AS/NZS 4357 certified. Uncertified or imported look-alikes can’t guarantee consistent structural properties, and as with formply, the installer carries the risk if a compliance claim can’t be backed with evidence.
What to look out for - a practical checklist
1. Load capacity and stiffness (the E-rating and section). LVL is used as bearers, joists, soldiers and walers — members carrying the full wet-concrete load. The two things that drive performance are the grade/modulus (LVL formwork beams are chosen for being among the highest load-bearing available) and the section depth. Deeper beams span further and deflect less. Never just eyeball this: match the beam to the load, span and spacing using the manufacturer’s span tables for your design. Achievable spans change with depth, load and spacing, so the table is the deciding document, not a rule of thumb.
2. Deflection control. For formwork, stiffness often matters more than raw strength — excess deflection between supports puts sag and steps into your slab soffit. Size the member to the deflection limit in the span table, not just the strength limit.
3. The moisture-repellent coating — this is the big one for formwork LVL. This is what separates purpose-built formwork LVL from ordinary structural LVL. Formwork lives in a wet, alkaline, corrosive environment (fresh concrete, bleed water, repeated pours). Look for a high wax-loaded moisture-repellent coating (Wesbeam e-form is built exactly this way). The high wax loading improves dimensional stability, stops the beam drinking up water and moving, and extends service life — which is what makes it cost-effective over many reuses. A coating that’s too light means swelling, bowing and a short working life.
4. Straightness and dimensional stability. The whole point of engineered LVL over sawn timber is that it’s consistently straight and stays straight under load and moisture. Straight bearers and joists give you a true, flat form and a clean soffit; they also need fewer props and less packing to bring level.
5. Durability / hazard treatment for the environment. Check whether the application needs a treatment level (e.g. H2-S, H3) for termite or moisture exposure, particularly for beams that may sit in damp or ground-contact conditions or get long reuse cycles.
6. On-site identification and handling. A small thing that saves real time on a busy deck: FormBEAM is painted bright orange with ends colour-coded by length, so the crew grabs the right beam first time and cuts handling. When you’re cycling forms floor to floor, fast, error-free selection matters.
7. Reuse economics — think cost-per-pour, not sticker price. Like formply, the value of good formwork LVL is realised over many pours. A well-coated, dimensionally stable beam that stays straight and resists moisture will outlast a cheaper one several times over, so the true measure is cost per use across the job.
8. System compatibility and availability. Match beam depths and widths to your formply, decking and support system so everything works together, and confirm your branch actually stocks the sizes and lengths you need (lengths commonly run in set increments up to ~13.2m, with longer available). Sourcing bearers, joists, formply and accessories from one supplier keeps the system compatible and the delivery in one drop.
An overview of the Big River formwork LVL products
FormBEAM LVL — Big River’s own-brand formwork beam, engineered specifically for structural formwork as bearers, joists, soldiers and walers across residential, commercial and civil work. Its signature is the bright-orange paint with length colour-coded ends for fast, error-free selection on site.
Wesbeam e-form — a premium, high-load formwork LVL made from slow-grown plantation veneers, and one of the highest load-bearing formwork LVL beams in Australia. Its standout feature is the high wax-loaded moisture-repellent coating for dimensional stability and long life in wet, corrosive pour environments — the one to reach for on demanding, high-reuse commercial work.
TruForm LVL beams — structural LVL manufactured to AS/NZS 4357 with independently audited, EWPAA-certified quality control; a dependable, certified formwork bearer/joist option.
The bottom line: start with AS/NZS 4357 certification, then size every member off the span tables for your actual load/span/spacing, prioritise a genuine high-wax moisture coating for anything facing repeated pours, and weigh it on cost-per-pour rather than the price per length. Your local branch can advise on grade, section, treatment and system compatibility for the specific application. We are here to help build your reputation, so always check with your Big River Formwork Specialist to make sure you select the right product for your specific concrete formwork application.
Getting the most from your Formwork LVL
To get more out of the Formwork LVL, here are some best practice tips for handling, care and the bottom line.
- Design to the span tables
- Protect the coating
- Store flat, dry & off the ground
- Order the whole system together
A helpful Formwork LVL selection guide
